Steel Casing

Core Parameters

• Product Name: Steel Casing (Steel Casing Pipe)

  Material & Specifications: Seamless steel made of 20#, 45#, DZ40, DZ50, R780, N80, J55 alloy steel and Q235B/Q355B carbon steel, fully compliant with API 5CT and SY/T0413-2019 standards, with strict mechanical testing for reliable performance under complex conditions.

  Size Range: Customizable outer diameter, wall thickness, and length. Standard sizes 108–508mm OD, 4–30mm thickness, 3m/6m lengths, with large diameters up to DN300–DN3000mm.

  Connection Type: API threads (STC, LTC, BTC), flanged and welded connections available. CNC machining, submerged arc welding, 25kV spark and X-ray inspection for quality assurance.

  Product Features: High pressure and wear resistance, excellent sealing, anti-corrosion coating options (3PE, galvanizing, epoxy), service life over 30 years, 45° beveled ends for easy welding.

  Applications: Oil & gas drilling, water wells, mining, geological exploration, municipal pipeline crossing, cable protection, geothermal and chemical projects.

  Packaging: Export-standard wooden cases or steel bundles, waterproof, impact-resistant, fumigation available.

  MOQ: 10 pieces, bulk discount available.

  Delivery Time: 5–7 days stock, 7–15 days custom, urgent orders available.

  Payment Terms: T/T and L/C, negotiable for large orders.


• Our steel casing is a core supporting product for deep drilling and various high-pressure, complex working conditions. Its main function is to support borehole walls in deep wells, prevent collapse, isolate high-pressure formations and different media layers, and protect drilling tools and borehole safety. It can also serve as a channel for fluid and gas production, making it suitable for multi-field pipeline protection applications.

  Backed by strong manufacturing capability, the product is produced using a three-roll hydraulic plate rolling machine with progressive forming. Roundness is calibrated in real time using arc templates (roundness deviation ≤4‰D). From raw material procurement to final inspection, every process is strictly controlled according to international standards. It is certified under the ISO9000 quality management system and holds a national special equipment manufacturing license for pressure pipelines, ensuring stable and reliable performance of each casing. It is fully suitable for surface casing, technical casing, and production casing in oil and gas extraction, as well as casing for geological exploration and municipal trenchless crossing projects, ensuring safe and efficient project execution.


Custom Services

We provide professional full-spec customization for steel casing based on drilling depth, borehole size, formation pressure, media type, and installation requirements. Outer diameter, wall thickness, length, connection type, and material can all be customized, with optimized design for special conditions such as H₂S resistance, high temperature and high pressure, and high corrosion environments.

Our technical team offers one-stop support from design and process optimization to quality inspection and logistics. We also develop special-performance casing such as anti-collapse, acid-resistant, and wear-resistant types to ensure full compatibility with project requirements and safe, efficient operation.

Contact Us for Quotation

Specifications

Key Advantages

✔High Pressure Resistance: Made of high-quality alloy steel with seamless forming process, thick wall and high strength (≥375MPa). It withstands downhole and industrial high-pressure conditions without deformation or rupture, effectively isolating formation pressure for safe and stable operation.

✔Reliable Sealing Performance:Precision-threaded connections and strictly tested welds ensure tight sealing, preventing fluid leakage and cross-layer contamination, suitable for underground and underwater environments.

✔Corrosion & Wear Resistance:Various anti-corrosion coatings are available. It resists groundwater, oil, gas, chemical media, and saline soil. For severe conditions, Inconel 625 cladding can be applied to extend service life.

✔Strict Quality Control:Full-process inspection from raw materials to finished products with traceability. X-ray tested welds, certified reports provided. Complies with API, ASTM, DIN standards.

✔Wide Compatibility: High dimensional accuracy with multiple connection options, suitable for complex formations such as hard rock and fractured strata. Customizable in size, material, and coating for oil, municipal, chemical, and power applications.

Applications

Our steel casing, with excellent high pressure resistance, corrosion resistance, and high strength, is widely used in deep drilling and industrial or municipal projects. It is suitable for complex formations and high-temperature, high-pressure conditions.

Inquiry & Support

Fill in Your Requirements
